Marklin 60195 - Power Pack 120V/100 VA for LGB and 1-Gauge



  • $109.98
    Unit price per
Shipping calculated at checkout.

  Shows to be in stock at Ajckids


Add to Wishlist

Scale: All Scales

UPC or EAN: 4001883601953

Product Description

This switched mode power pack is for connecting to and for powering the 60216, 60226, as well as 60214/60215 Central Stations, and the 60174 and 60175 Boosters.

The input is 120 volts / 60 Hertz, and the output is 19 volts / 100 watts DC voltage. Weatherproof (IP67) switched mode power pack.

Connections: 4-pin mini DIN high current plug.

Dimensions 190 mm x 96 mm x 65 mm / 7-1/2” x 3-3/4” x 2-9/16”. The 60195 switched mode power pack is designed for us in dry areas.

Recommended only for LGB and 1 Gauge.

Charlie's Tip: Marklin says that the cross section of the wire from the Central Station to the track must be at least 0.5 square millimeters / approximately 0.0008 square inches. What that means is that you should run at least 20 Gauge wire. Not the thin stuff we normally use for H0. But I would recommend running even thicker wire, like 18 Gauge or even 16 Gauge when the distances get longer. The thicker wire will minimize a power loss/voltage drop.



More Information

Manufacturer Marklin
Item 60195
Scale All Scales
Availability   Shows to be in stock
UPC or EAN (GTIN) 4001883601953
