Fascinating Museum Locomotive

Prototype: Express steam locomotive, road number 18 314 with oil firing and an oil tender, museum locomotive for the Sinsheim Technology Museum. Former Baden IVh. The locomotive looks as it did around 2021.

Highlights

• Completely new tooling.
• Highly detailed full metal construction.
• Frame, superstructure, boiler, etc. constructed of die-cast zinc, separately applied parts constructed of brass.
• Decoder generation with a current buffer and up to 32 functions.
• Smoke unit with smoke exhaust and f/r cylinder steam synchronized with the wheels and a steam whistle.
• Special function: The locomotive engineer activates the controller (servo activated)
• Load-controlled operating sounds synchronized with the wheels.
• Smoke box door and dome hatches can be opened, many original details included.
• Running gear lights that can be controlled.
• Headlights with a light color correct for the era and warm white LEDs.
• Red marker light that can be controlled.
• Cab lighting.
• mfx decoder for operation with AC power, DC power, Märklin Digital, and DCC.
• Valve gear switchover (forward, reverse, continuous operation) in 3 steps with a servomotor.
• Telex coupler on the rear, reproduction prototype coupler on the front (one (1) more of each included with the locomotive).

Product description

Model: The locomotive is completely new tooling constructed of metal. The frame, locomotive body with boiler, and the cab are constructed of die-cast zinc. Other separately applied parts are mostly constructed of metal (brass). This is an extensive model with many separately applied elements and a highly detailed cab. The smoke box door can be opened. The cab doors and much more can be opened.

The locomotive has an mfx digital decoder with 32 functions, controlled high efficiency propulsion, and a sound generator with operating sounds synchronized with the wheels as well as extensive sound functions. It can be operated with AC power, DC power, Märklin Digital, and DCC. The locomotive has a built-in buffer capacitor. All driving axles powered. The locomotive has a built-in smoke unit with smoke exhaust and multi-step cylinder steam synchronized with the wheels and a steam whistle. The locomotive has running gear lights and triple headlights with a light color correct for the era and that change over with the direction of travel. The headlights will work in conventional operation and can be controlled digitally.

Maintenance-free, warm white LEDs are used for the lighting. The locomotive has a red marker light that can be controlled and cab lighting. Digitally controlled special function: The locomotive engineer activates the controller (movement activated with a servo as when the locomotive engineer activates the controller in real life). The locomotive comes with sprung buffers. There is a reproduction of the prototype coupler on the front and a remote-controlled Telex coupler on the rear of the tender, which can be replaced by the other type of coupler. The valve gear switchover is in 3 steps (forward, reverse, continuous operation). There is a built-in figure of a locomotive engineer. An accessory package with a reproduction of the prototype coupler, smoke fluid, and gloves are included with the locomotive. The locomotive is mounted on an aluminum base painted black for display purposes.

Minimum radius for operation 1,020 mm / 40-3/16".

Length over the buffers approximately 73.8 cm / 29". Weight approximately 9.2 kilograms / 20 pounds 4 ounces.

Publications

Prototype information

The "Schorsch" – A Unique One-of-a-Kind on the German State Railroad (DR). Road number 18 314 of the German State Railroad (DR) of the GDR, a steam locomotive later known as the "Schorsch", had an unusual, astonishing life story. Once put into service in 1919 as a Baden class "IV h" "classy runner", the DRG took over this unit as road number 18 314. After the end of World War II, it went to the Soviet Zone in exchange for an S 3/6, where the later VES-M Halle (Railroad Research and Development Locomotive Management Department) urgently needed a fast four-cylinder compound steam locomotive for experimental runs.

In 1960, it was equipped with a rebuilt boiler, partial streamlining, a new cab, and tender as well as a green paint scheme in order to go even faster. The final "i" was dotted in 1967 when it was converted to oil firing. At the end of 1971, it was put into storage and sold to West Germany in 1984 in die BRD. Since 1986, it has formed one of the showpieces in the Automotive and Technology Museum in Sinsheim. It is on permanent loan from the HEF.
