Marklin 36618 - SNCB Class 29 Electric Locomotive

  • Marklin 36618 - SNCB Class 29 Electric Locomotive
1 2

$000
Sale Sold out
Shipping calculated at checkout.

Sold out

Add To Wishlist

Scale: H0-Scale

EAN/UPC: 4001883366180

System: 3-Rail AC (Märklin).

Instruction Manual

View full details

Prototype: Alpha Trains NV/SA, Antwerp, Belgium class E 186 general-purpose electric locomotive, leased as the class 29 to the Belgium State Railways (SNCB). Two-system locomotive with 4 pantographs. The locomotive looks as it did around 2012.

Model: The locomotive has an mfx digital decoder and extensive sound functions. It also has a special motor, centrally mounted. 4 axles powered through cardan shafts. Traction tires. The triple headlights and dual red marker lights change over with the direction of travel, will work in conventional operation, and can be controlled digitally. The headlights at Locomotive Ends 2 and 1 can be turned off separately in digital operation. When the headlights at both ends of the locomotive are turned off, then there is a double "A" light function at both ends. Warm white and red LEDs are used for the lighting. The locomotive has 4 mechanically working pantographs that are not wired to take power.

Length over the buffers 21.7 cm / 8-1/2".

Highlights
  • Locomotive includes a wide variety of light and sound functions.
  • mfx decoder included.
  • Warm white and red LEDs for the lighting.
  • Metal body for the locomotive.

Publications

- New items brochure 2017 - Product programme 2017/2018

Features

) Metal frame and locomotive body.
e Digital decoder with up to 32 digitally controlled functions. The quantity depends on the controller being used.
§ DCC decoder
h Built-in sound effects circuit.
G Triple headlights front and rear.
N Triple headlights and two red marker lights that change over with the direction of travel.
T Märklin close couplers in standard pocket with pivot point.
8 Era 6
Y

Warning

ATTENTION: adults only
ATTENTION: not for children under 15 years
Control Unit Mobile Station Mobile Station 2 Central Station 1/2 Central Station 3/2
Headlight(s) X X X X X
Operating Sounds 1 X X X X X
Electric locomotive op. sounds X X X X X
Horn X X X X X
Direct control X X X X X
Sound of squealing brakes off X X X X
Headlight(s): Cab2 End X X X X
Whistle for switching maneuver X X X X
Headlight(s): Cab1 End X X X X
Sound of Couplers Engaging X X X
Operating Sounds 2 X X X
Letting off steam / air X X X
Blower motors X X X
Conductor's Whistle X X X
Sanding X X X

EAN/UPC: 4001883366180
